Integral Revolver
Integral Revolver
Integral Revolver
Brinell, Easydur, Universal
Automatic hardness testing machine
with test loads from 0.1 to 3000 kgf.
Motorized rotating turret up to 8 positions.
LD750 / LD250
Integral Revolver
Integral Revolver
Affri, Brinell, Universal
Automatic hardness testing machine
with test loads from 1 to 3000 kgf.
Touchscreen PC with preinstalled software.
LD3000AX
WK SERIES
WK SERIES
Affri, Brinell, Universal
Automatic hardness testing machine
with test loads from 1 to 3000 kgf.
Auto Contact, Clamping & Compensation.
WK SERIES
WK SERIES
WK SERIES
Affri, Brinell, Universal
Semi-automatic hardness testing machine
with test loads from 3 to 250 kgf.
Suitable for small samples.
Integral Revolver
Test loads
from 1 to 3000 kgf (from 9,807 to 29421 N) – As optional from 0,1 kgf (0,9807 N)
Rockwell ISO 6508 / ASTM E-18:
HRA – HRB – HRC – HRD – HRE – HRF – HRG – HRH – HRK – HRL – HRM – HRP – HRR – HRS – HRV HR15N/T/S/W/X/Y – HR30N/T/S/W/X/Y – HR45N/T/S/W/X/Y
Brinell HBW ISO 6506 / ASTM E-10
HBW1/30 – HBW2.5/15.625 – HBW2.5/31.25 – HBW2.5/62.5 – HBW2.5/187.5 – HBW5/25 – HRW5/62,5 – HBW5/125 – HBW5/250 – HBW5/750 – HBW10/100 – HBW10/250 – HBW10/500 – HBW10/1000 – HBW10/1500 – HBW10/3000 HBWT2.5/62.5 – HBWT2.5/187.5 – HBWT5/125 – HBWT5/250 – HBWT5/750 – HBWT10/500 – HBWT10/1000 – HBWT10/1500 – HBWT10/3000
BRINELL HBWT ASTM E103
HBWT2.5/62.5 – HBWT2.5/187.5 – HBWT5/125 – HBWT5/250 – HBWT5/750 – HBWT10/500 – HBWT10/1000 – HBWT10/1500 – HBWT10/3000
Vickers ISO 6507 / ASTM E-384 / ASTM E-92
HV1 – HV2 – HV3 – HV5 – HV10 – HV20 – HV30 – HV50 – HV100 Optional: HV0,1 – HV0,2 – HV0,3 – HV0,5
Standards
EN-ISO 6506-2 / EN-ISO 6507-2 / EN-ISO 6508-2 / EN-ISO 2039 / EN-ISO 868 / ASTM E-18 / ASTM E-10 / ASTM E-384 / ASTM E-92 / ASTM E-2240 / JIS
Testing Base
390 x 295 mm
Height Capacity
0-500 mm / 0-20" Motorized
Depth Capacity
280 mm / 11"
Force Range
Rockwell: 588.4 - 980.7 - 1471 N (60 - 100 - 150 kgf)
Superficial Rockwell: 147.1 - 294.2 - 441.3 N (15 - 30 - 45 kgf)
Brinell: 9.807 - 24.52 - 49.03 - 61.29 - 98.07 - 153.2 - 245.2 - 294.2 - 306.5 - 612.9 - 980.7 - 1226 - 1839 - 2451 - 4903 - 7355 - 9807 - 14710 - 29421 N ( 1 - 2,5 - 5 - 6.25 - 10 - 15.6 - 25 - 30 - 31.2 - 62.5 - 100 - 125 - 187.5 - 250 - 500 - 750 - 1000 - 1500 - 3000 kgf). From 1 to 3000kgf
Vickers - Knoop: 9.807 - 29.42 - 49.03 - 98.07 - 147.1 - 196 - 294.2 - 490.35 - 980.7 N (1 - 3 - 5 - 10 - 15 - 20 - 30 - 50 - 100 kgf)
Optional tests: 49 - 132 - 358 - 961 N (For plastics and rubbers as per EN-ISO 2039 std)
Shore A - D
Feasible Tests
Rockwell: HRC - HRA - HRD - HRB - HRF - HRG - HRL - HRM - HRR
Superficial Rockwell: HRN - HRT - HRS - HRW - HRX - HRY
Brinell: HBW 1/1 – HBW 1/1.25 – HBW 1/2.5 – HBW 1/5 – HBW 1/10 – HBW 1/30 – HBW 2.5/6.25 – HBW 2.5/7.8125 - HBW 2.5/15.625 – HBW 2.5/31.25 – HBW 2.5/62.5 – HBW 2.5/187.5 – HBW 5/25 – HBW 5/31.25 – HBW 5/62.5 – HBW 5/125 – HBW 5/250 – HBW 5/750 – HBW 10/100 – HBW 10/125 – HBW 10/250 – HBW 10/500 – HBW 10/1000 – HBW 10/1500 – HBW 10/3000
Vickers - Knoop (Only indentation): HV1 - HV3 - HV5 - HV10 - HV15 - HV20 - HV30 - HV50 - HV100
Shore A - D
Preload
29.4 - 98.1 N (3 - 10 kgf)
Load accuracy
Better than 0.1%
LD750 / LD250
Test Loads
LD250: From 1 to 250 kgf (9,807 to 2452 N)
LD750: From 3 to 3000 kgf (29.4 to 29421 N)
Rockwell ISO 6508 / ASTM E-18:
HRA – HRB – HRC – HRD – HRF – HRG – HRL – HRM – HRR / HRN – HRT – HRS – HRW – HRX – HRY
Brinell HBW ISO 6506 / ASTM E-10
HBW1/30 – HBW2.5/15.625 – HBW2.5/31.25 – HBW2.5/62.5 – HBW2.5/187.5 – HBW5/25 – HRW5/62,5 – HBW5/125 – HBW5/250 – HBW5/750 – HBW10/100 – HBW10/250 – HBW10/500 – HBW10/1000 – HBW10/1500 – HBW10/3000
Brinell HBWT ASTM E103
HBWT2.5/62.5 – HBWT2.5/187.5 – HBWT5/125 – HBWT5/250 – HBWT5/750 – HBWT10/500 – HBWT10/1000 – HBWT10/1500 – HBWT10/3000
Vickers ISO 6507 / ASTM E-384 / ASTM E-92
HV1 – HV2 – HV3 – HV5 – HV10 – HV20 – HV30 – HV50 – HV100
Standards
EN-ISO 6506-2 / EN-ISO 6507-2 / EN-ISO 6508-2 / EN-ISO 2039 / ISO 868 / ASTM-E10 / ASTM-E18 / ASTM-E103 / ASTM 2240 / ASTM-E384 / JIS
Indenter Stroke
Motorized 30 mm / 1.2" with automatic contact
Height Capacity
LD750: Motorized 720mm / 28″ (more on request)
LD250: Motorized 390mm / 15″ (more on request)
Depth Capacity
LD750: 265 mm / 10.5” (more on request)
LD250: 190 mm / 7.5” (more on request)
Working Table
LD750: 480 x 675 mm / 19 x 26 “ (more on request)
LD250: 330 x 390 mm / 13 x 15.5 “ (more on request)
Preload
29.4 - 98.1 N (3 - 10 kgf)
Load accuracy
Better than 0.1%
Force Range
Depending on the models:
Rockwell: 588.4 - 980.7 - 1471 N (60 - 100 - 150 kgf)
Superficial Rockwell:
147.1 - 294.2 - 441.3 N (15 - 30 - 45 kgf)
Brinell:
9.807 - 24.52 - 49.03 - 61.29 - 98.07 - 153.2 - 245.2 - 294.2 - 306.5 - 612.9 - 1226 - 1839 - 2452 - 4903 - 7355 - 9870 - 14710 - 29421N
(1 - 2.5 - 5 - 6.25 - 10 - 15.625 - 25 - 30 - 31.2 - 62.5 - 125 - 187.5 - 250 - 500 - 750 - 1000 - 1500 - 3000kgf)
Vickers - Knoop:
9.807 - 29.42 - 49.03 - 98.07 - 147.1 - 196 - 294.2 - 490.35 - 980.7 N (1 - 3 - 5 - 10 - 15 - 20 - 30 - 50 - 100 kgf)
Optional tests:
49 - 132 - 358 - 961 N (For plastics and rubbers as per EN-ISO 2039 std)
Shore A - D
Feasible Tests
Depending on the models:
Rockwell:
=HRA - HRB - HRC - HRD - HRE - HRF - HRG - HRH - HRK - HRL - HRM - HRP - HRR - HRS - HRV
Superficial Rockwell:
HR15N/T/S/W/X/Y - HR30N/T/S/W/X/Y - HR45N/T/S/W/X/Y
Brinell HBW: HBW 1/1 – HBW 1/1.25 – HBW 1/2.5 – HBW 1/5 – HBW 1/30 – HBW 2.5/6.25 – HBW 2.5/7.8125 - HBW 2.5/15.625 – HBW 2.5/31.25 – HBW 2.5/62.5 – HBW 2.5/187.5 – HBW 5/25 – HBW 5/31.25 – HBW 5/62.5 – HBW 5/125 – HBW 5/250 – HBW 5/750 – HBW 10/100 – HBW 10/125 – HBW 10/250 – HBW 10/500 – HBW 10/1000 – HBW 10/1500 – HBW 10/3000
Brinell HBWT:
1/30 - 2.5/15.6 - 2.5/31.5 - 5/125(3) (Aluminum and alloys) - 2.5/62.5(2) (Aluminum and alloys) - 2.5/187.5(6) (Aluminum and alloys) - 2.5/187.5(5) (Carbon steel) - 2.5/187.5(1) (Cast iron) - 5/125 - 5/250 - 5/750 - 10/500 - 10/1000 - 10/1500 - 10/3000
Vickers - Knoop: HV1 - HV3 - HV5 - HV10 - HV15 - HV20 - HV30 - HV50 - HV100
Shore A - D
LD3000AX
Test Loads
From 1 to 250 kgf (9,807 to 2452 N) From 3 to 3000 kgf (29.4 to 29421 N)
Rockwell ISO 6508 / ASTM E-18
HRA – HRB – HRC – HRD – HRE – HRF – HRG – HRH – HRK – HRL – HRM – HRP – HRR – HRV / HRN – HRT – HRS – HRW – HRX – HRY
Brinell HBW ISO 6506 / ASTM E-10 – HBWT ASTM E103
HBW 1/1 – HBW 1/1.25 – HBW 1/2.5 – HBW 1/5 – HBW 1/30 – HBW 2.5/6.25 – HBW 2.5/7.8125 – HBW 2.5/15.625 – HBW 2.5/31.25 – HBW 2.5/62.5 – HBW 2.5/187.5 – HBW 5/25 – HBW 5/31.25 – HBW 5/62.5 – HBW 5/125 – HBW 5/250 – HBW 5/750 – HBW 10/100 – HBW 10/125 – HBW 10/250 – HBW 10/500 – HBW 10/1000 – HBW 10/1500 – HBW 10/3000
Vickers ISO 6507 / ASTM E-384 / ASTM E-92
HV1 – HV2 – HV3 – HV5 – HV10 – HV20 – HV30 – HV50 – HV100
Standards
EN-ISO 6506-2 / EN-ISO 6507-2 / EN-ISO 6508-2 / EN-ISO 2039 / ISO 868 / ASTM-E10 / ASTM-E18 / ASTM-E103 / ASTM 2240 / ASTM-E384 / JI
Indenter Stroke
Motorized 30 mm / 1.2" with automatic contact
Height Capacity
300 mm / 12" (more on request)
Depth Capacity
190 mm / 7.4” (more on request)
Preload
29.4 - 98.1 N (3 - 10 kgf)
Load accuracy
Better than 0.1%
Force Range
Depending on the models:
Rockwell: 588.4 - 980.7 - 1471 N (60 - 100 - 150 kgf)
Superficial Rockwell: 147.1 - 294.2 - 441.3 N (15 - 30 - 45 kgf)
Brinell: 9.807 - 24.52 - 49.03 - 61.29 - 98.07 - 153.2 - 245.2 - 294.2 - 306.5 - 612.9 - 1226 - 1839 - 2452 - 4903 - 7355 - 9870 - 14710 - 29421N
(1 - 2.5 - 5 - 6.25 - 10 - 15.625 - 25 - 30 - 31.2 - 62.5 - 125 - 187.5 - 250 - 500 - 750 - 1000 - 1500 - 3000kgf)
Vickers - Knoop: 9.807 - 29.42 - 49.03 - 98.07 - 147.1 - 196 - 294.2 - 490.35 - 980.7 N (1 - 3 - 5 - 10 - 15 - 20 - 30 - 50 - 100 kgf)
Optional tests: 49 - 132 - 358 - 961 N (For plastics and rubbers as per EN-ISO 2039 std)
Shore A - D
Feasible Tests
Depending on the models:
Rockwell: HRA - HRB - HRC - HRD - HRE - HRF - HRG - HRH - HRK - HRL - HRM - HRP - HRR - HRS - HRV
Superficiale Rockwell: HR15N/T/S/W/X/Y - HR30N/T/S/W/X/Y - HR45N/T/S/W/X/Y
Brinell HBW: HBW 1/1 – HBW 1/1.25 – HBW 1/2.5 – HBW 1/5 – HBW 1/30 – HBW 2.5/6.25 – HBW 2.5/7.8125 - HBW 2.5/15.625 – HBW 2.5/31.25 – HBW 2.5/62.5 – HBW 2.5/187.5 – HBW 5/25 – HBW 5/31.25 – HBW 5/62.5 – HBW 5/125 – HBW 5/250 – HBW 5/750 – HBW 10/100 – HBW 10/125 – HBW 10/250 – HBW 10/500 – HBW 10/1000 – HBW 10/1500 – HBW 10/3000
Brinell HBWT: 1/30 - 2.5/15.6 - 2.5/31.5 - 5/125(3) (Aluminum and alloys) - 2.5/62.5(2) (Aluminum and alloys) - 2.5/187.5(6) (Aluminum and alloys) - 2.5/187.5(5) (Carbon steel) - 2.5/187.5(1) (Cast iron) - 5/125 - 5/250 - 5/750 - 10/500 - 10/1000 - 10/1500 - 10/3000
Vickers - Knoop: HV1 - HV3 - HV5 - HV10 - HV15 - HV20 - HV30 - HV50 - HV100
Shore A - D
WK Series
250 DRM WKC
250 DRM WKC
250 DRM WKC
- 3 to 250 kgf
- Rockwell, Superficial R., Brinell and Vickers
- Motorized electronic load cells loading system
- Clamping system available
- Direct reading HR and HBW
206 EX2 WK
250 DRM WKC
250 DRM WKC
- 3 to 187.5 kgf
- Rockwell, Superficial R., Brinell and Vickers
- Dual load cells loading system
- Clamping system available
- Direct reading HR and HBW
206 EX WK
250 DRM WKC
206 EX WK
- 3 to 31.25 kgf or 10 to 187.5kgf
- Rockwell, Brinell and Vickers or Superficial R., Brinell and Vickers
- Dual load cells loading system
- Clamping system available
- Direct reading HR and HBW
